Product Specifications
Warranty Information
|
Intel Socket Compatibility
|
1700, 1200, 115X, 2011-3*, 2066* (*Square ILM)
|
|
AMD Socket Compatibility
|
AM5, AM4
|
|
RAM Clearance
|
Unlimited
|
|
Operating Ambient Temperature
|
0 - 40 °C
|
|
Cooler Connector
|
4-Pin PWM
|
|
LEDs Connector
|
4-Pin 12V-G-R-B Connector with Y-Splitter
|
|
VRM Fan
|
40 mm, 1000–3000 rpm (PWM controlled)
|
|
Pump Speed
|
800–2000 rpm (PWM controlled)
|
|
Pump Power Consumption
|
0.5 W–2.7 W (Pump and VRM Fan)
|
|
Base Plate Material
|
Copper, Micro Skived Fin
|
|
Thermal Compound
|
MX-5 (0.8g)
|
|
Fans
|
2x ARCTIC P12 PWM A-RGB – 120 mm
|
|
Fan Speed
|
200–1800 rpm
|
|
Fan Bearing
|
Fluid Dynamic Bearing
|
|
Fan Noise Level
|
0.3 Sone
|
|
Fan Current
|
0.08 A
|
|
Fan Airflow
|
48.8 CFM
|
|
Fan Static Pressure
|
1.85 mm H2O
|
|
Fan Connection
|
4-pin connector
|
|
RGB LEDs per Fan
|
12 A-RGB LEDs
|
|
RGB Connector
|
3-Pin 5 V-DI-Gnd
|
|
RGB Current/Voltage
|
0.4 A
|
|
Radiator Dimensions
|
277 x 120 x 38 mm
|
|
Pump Dimensions (without Hoses)
|
98 mm x 78 mm x 53 mm
|
|
Hose Diameter (Outside)
|
12.4 mm
|
