Product Specifications
Warranty Information
|
Dimensions
|
120 x 78.5 x 21 mm (4.72 x 3.09 x 0.82 inches)
|
|
Antenna Type
|
Two High-Gain Dual Band Antennas
|
|
Chipset
|
Intel Wi-Fi 6 Chipset
|
|
Bluetooth Standards
|
Bluetooth 5.2, 5.0, 4.2, 4.0
|
|
Bluetooth Interface
|
F_USB 2.0
|
|
Wireless Standards
|
IEEE 802.11ax/ac/n/a (5 GHz), IEEE 802.11ax/n/g/b (2.4 GHz)
|
|
WLAN Signal Rate (5 GHz)
|
11ax: Up to 2402 Mbps, 11ac: Up to 1733 Mbps, 11n: Up to 300 Mbps, 11a: Up to 54 Mbps
|
|
WLAN Signal Rate (2.4 GHz)
|
11ax: Up to 574 Mbps, 11n: Up to 300 Mbps, 11g: Up to 54 Mbps, 11b: Up to 11 Mbps
|
|
WLAN Transmit Power
|
5 GHz: 27dBm(FCC) / 23dBm(CE), 2.4 GHz: 26dBm(FCC) / 20dBm(CE)
|
|
Wireless Security
|
64/128 bit WEP, WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x
|
|
System Requirements
|
Windows 10 (64-bit) only
|
|
Operating Temperature
|
0℃~40℃ (32℉~104℉)
|
|
Storage Temperature
|
-40℃~70℃ (-40℉~158℉)
|
