| Specification | Details |
| Graphics Processor | NVIDIA GeForce RTX 5080 |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 10,752 |
| Base Clock | 2295 MHz |
| Boost Clock | 2617 MHz |
| Memory Amount | 16 GB |
| Memory Type | GDDR7 |
| Memory Interface | 256-bit |
| Memory Speed | 30 Gbps |
| Memory Bandwidth | 960 GB/sec |
| Bus Support | PCI-E 5.0 x16 |
| Ray Tracing Cores | 4th Generation |
| Tensor Cores | 5th Generation |
| NVIDIA Encoder (NVENC) | 2 x 9th Generation |
| NVIDIA Decoder (NVDEC) | 2 x 6th Generation |
| Thermal & Power Solution | Triple Fan (TurboFan 4.0, Composite Heat Pipe, Copper Base, 0-dB Tech) |
| Graphics Card Power | 360 W |
| Recommended System Power | 850 W |
| Supplementary Power Connectors | 16-pin x1 (12V-2x6) |
| Display Outputs | 1x HDMI 2.1b, 3x DisplayPort 2.1b |
| Maximum Digital Resolution | 4K at 480Hz or 8K at 120Hz with DSC |
| Multi-Monitor Support | Up to 4 Displays |
| DirectX Version | Microsoft DirectX 12 Ultimate |
| OpenGL Version | 4.6 |
| Vulkan Version | 1.4 |
| Slot Width | 2.8 Slot |
| Board Dimensions | 331.9 x 127.1 x 56.8 mm |
| Key Features | DLSS 4.5, NVIDIA Reflex 2, Broadcast, Resizable BAR, G-SYNC, VR Ready, ThunderMaster Support |
| Included Accessories | Power Cable Adapter |
