MSI B550M Gaming Plus
- Compatible with AMD Ryzen™ 5000, 4000 G-Series, and 3000 Series desktop processors (except Ryzen™ 5 3400G & Ryzen™ 3 3200G)
- Supports high-speed DDR4 memory up to 4400MHz (overclocked), dual-channel with 4 DIMM slots (max 128GB)
- Lightning-fast PCIe 4.0, dual M.2 slots (one Gen 4 x4) with M.2 Shield Frozr for ultimate storage speeds
- Advanced power design with Core Boost, digital PWM, and thickened copper PCB for reliable performance
- Premium thermal solution: Extended heatsinks and M.2 thermal shield for sustained high loads and cool temps
- Pre-installed I/O shield for clean installation and extra EMI protection
- Flash BIOS Button—update your BIOS safely and quickly via USB, plus optimized ClearCMOS for easy defaults restore
- Studio-grade sound with Audio Boost and support for multi-GPU AMD CrossFire setups
|
CPU Socket
|
AM4
|
|
Chipset
|
AMD B550
|
|
Memory Support
|
DDR4, 4 DIMM slots, up to 128GB, 4400(OC) MHz
|
|
PCIe Slots
|
2 x PCIe x16, 2 x PCIe x1 (PCIe 4.0 support)
|
|
Storage
|
6 x SATAIII, 2 x M.2 (1 x PCIe 4.0 x4, 1 x PCIe 3.0 x4)
|
|
RAID
|
0, 1, 10
|
|
USB Ports (Front)
|
1 x Gen 1 Type-C, 2 x Gen 1 Type-A, 4 x USB 2.0
|
|
USB Ports (Rear)
|
1 x Gen 2 Type-C, 1 x Gen 2 Type-A, 2 x Gen 1 Type-A, 4 x USB 2.0
|
|
Audio
|
Realtek® ALC892/ALC897, Audio Boost
|
|
Video Output
|
1 x HDMI, 1 x DisplayPort
|
|
Networking
|
1 x RJ45 (LAN)
|
|
TPM Header
|
Yes
|
|
DirectX
|
12
|
|
Multi GPU
|
AMD CrossFire supported
|
|
Board Size
|
ATX
|
MSI B550 Gaming Plus
100907 / 1 Year WarrantyGet notified when this item is back in stock
