| Specification | Details |
| Model | AU6 |
| Form Factor | M-ATX / ITX |
| Structure Dimensions (L x W x H) | 420 x 215 x 395 mm |
| Product Dimensions (L x W x H) | 457 x 215 x 407 mm |
| Package Dimensions (L x W x H) | 450 x 275 x 524 mm |
| Structure Thickness | 0.5 mm |
| Materials | SPCC, tempered glass, plastic |
| Side Panel | Tempered glass |
| Drive Bays | 1 x 3.5" HDD + 1 x 2.5" SSD |
| CPU Cooler Max Height | 170 mm |
| GPU Max Length | 390 mm |
| PCI Card Slots | 4 |
| Front Fan Support | 3 x 120 mm / 2 x 140 mm |
| Top Fan Support | 3 x 120 mm / 2 x 140 mm |
| Side Fan Support | 2 x 120 mm |
| Bottom Fan Support | 2 x 120 mm |
| Rear Fan Support | 1 x 120 mm |
| Liquid Cooling Support | Top: 360 mm, 240 mm / Front: 360 mm, 240 mm |
| Power Supply Support | Non-modular PSU: 170 mm / Modular PSU: 150 mm (Bottom/Front mounted up to 180 mm) |
| I/O Panel | 1 x USB 3.0, 1 x USB 2.0, HD Audio, Power Button, Reset Button |
| Net Weight | 4.8 kg ± 10% |
| Gross Weight | 5.5 kg ± 10% |
