| Specification | Detail |
| Model | PB8 |
| Structure Dimensions (L x W x H) | 459 x 220 x 467 mm |
| Product Dimensions (L x W x H) | 479 x 220 x 480 mm |
| Package Dimensions (L x W x H) | 521 x 277 x 553 mm |
| Structure Thickness | 0.5 mm |
| Materials | SPCC, Tempered Glass |
| Form Factor Support | ATX / Micro-ATX / ITX / E-ATX (unless side fans are mounted) |
| Drive Bays | 2 x 3.5" HDD + 2 x 2.5" SSD or 1 x 3.5" HDD + 3 x 2.5" SSD |
| CPU Cooler Max Height | 174 mm |
| GPU Max Length | 420 mm |
| Top I/O Panel | 1 x USB 3.0, 1 x USB 2.0, 1 x Type-C, HD Audio, LED Control Button, Reset Button, Power Button |
| PCI Card Slots | 7 |
| Fan Support |
Top: 3 x 120 mm / 2 x 140 mm Rear: 1 x 120 mm / 1 x 140 mm Side: 2 x 120 mm Bottom: 3 x 120 mm |
| Liquid Cooling Support | Top: 360 mm / 240 mm |
| Power Supply Support | Bottom-mounted ATX PSU (up to 240 mm) |
| Net Weight | 6.4 kg ± 10% |
| Gross Weight | 7.5 kg ± 10% |
