xOVERVIEW
The AMD Ryzen 5 5500 is a desktop processor with 6 cores, launched in April 2022 at $159. It uses the Zen 3 architecture with Socket AM4, with 12 threads and 16MB of L3 cache. The chip is manufactured on a 7 nm production node using 10,700 million transistors. Overclocking is easy with the unlocked multiplier. With a 65 W TDP, it supports DDR4 memory with a dual-channel interface and supports 3200 MHz.
It uses a PCI-Express Gen 3 connection for communication and does not have integrated graphics. Hardware virtualization is available, enhancing performance for calculation-heavy applications.
PRODUCT SPECIFICATIONS
| GENERAL |
|
Regional Availability
|
Global, China, NA, EMEA, APJ, LATAM
|
| Platforms | Desktop |
| Product Family |
AMD Ryzen™ Processors
|
| Product Line |
AMD Ryzen™ 5 Desktop Processors
|
|
# of CPU Cores
|
6 |
|
# of Threads
|
12 |
|
Max. Boost Clock
|
Up to 4.2GHz
|
|
Base Clock
|
3.6GHz |
|
L1 Cache
|
384KB
|
|
L2 Cache
|
3MB |
|
L3 Cache
|
16MB |
|
Default TDP
|
65W
|
|
Processor Technology for CPU Cores
|
TSMC 7nm FinFET |
| Unlocked for Overclocking | Yes |
|
CPU Socket
|
AM4 |
|
Socket Count
|
1P |
|
Thermal Solution (PIB)
|
AMD Wraith Stealth
|
|
Max. Operating Temperature (Tjmax)
|
90°C
|
|
Launch Date
|
4/4/2022 |
|
OS Support
|
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
|
| CONNECTIVITY |
|
PCI Express® Version
|
PCIe 3.0
|
|
System Memory Type
|
DDR4
|
|
Memory Channels
|
2
|
|
System Memory Specification
|
Up to 3200MHz
|
|
Max Memory Speed
|
2x1R
DDR4-3200 2x2R
DDR4-3200 4x1R
DDR4-2933 4x2R
DDR4-2667 |
| KEY FEATURES |
Support Technologies:
|
