1 / 1

Deepcool

Deepcool Gamerstorm PF600X 600W (Silver)

BND 69.00

Hurry up! Stock running low!

Estimated delivery: Jun 07 - Jun 11

Product Information

• Triple Bronze Efficiency: Validated by 80 PLUS, Cybenetics, and PPLP badges to ensure 88% efficiency under typical loads, reducing energy waste and heat while extending the unit's operational life.

• Premium Capacitor Blend: Built with high-grade Taiwanese solid and electrolytic capacitors alongside premium Japanese brands on the 5V standby rail to secure a hold-up time > 16ms and a four-fold standby lifespan.

• Intel ATX 2.52 Topology: Combines Active PFC, Double Forward, and a DC-to-DC circuit with a dual-stage EMI filter to drop ripple noise and eliminate voltage deviations for high-performance hardware stability.

• Wide Voltage Adaptation: Operates seamlessly across 180V–264V grids and guards against sudden voltage drops down to 160V, protecting your system from unexpected low-voltage brownout shutdowns.

• Eight-Layer Safeguard ICs: Features an advanced protective matrix including OPP, OVP, SCP, OTP, OCP, UVP, SIP, and NLO, guaranteeing strict global safety compliance under high temperatures and high altitudes up to 5000m.

• Aerodynamic 40K Hr Fan: Includes a high-quality bearing fan with an optimized PCB flow resistance design that supports continuous 24/7 operation in 40°C environments while reducing overall system noise.

Product Summary

The Deepcool Gamerstorm PF600X 600W Power Supply delivers multi-certified Bronze efficiency, advanced DC-to-DC topology, and premium Japanese and Taiwanese capacitors. Optimized for Intel ATX 2.52 standards, this unit provides wide-voltage protection and custom-sleeved cabling to ensure quiet, ultra-stable performance for your desktop setup.

View details

Product Specifications

Warranty Information

Reviews

Specification	Details
Model	Deepcool Gamerstorm PF600X (Silver)
Total Output Power	600W
Efficiency Badges	80 PLUS Bronze (230V EU), Cybenetics Bronze (230V), PPLP Bronze (230V)
Typical Efficiency	88% under 50% load
Circuit Design	Active PFC + Double Forward + DC to DC
Compatibility Standard	Intel ATX 2.52 compliant with dual-stage EMI circuit
Supported Grid Voltage	180V–264V AC range (Maintains full-load operation down to 160V low-voltage grid)
Capacitor Configuration	Taiwanese premium solid & electrolytic capacitors; dual Japanese brand 5V Stand-By electrolytic capacitors
Hold-Up Time	$\ge \text{16ms}$ under 75% load conditions
Integrated Safeguards	OPP, OVP, SCP, OTP, OCP, UVP, SIP, NLO protection ICs
Environmental Safety Ratings	Rated for 40°C ambient temperature and 5000m high-altitude operation
Cooling Fan Lifespan	40,000 Hours MTBF (Supports 7×24 hrs continuous runtime at 40°C)
Acoustic / Thermal Engineering	Aerodynamic PCB layout and customized flow resistance design
Cable Configuration	GAMER STORM custom-molded sleeved cables
Main Power Connector	24 (20+4) Pin x1 (550 mm)
CPU Power Connector	(4+4) Pin x2 (620 mm + 150 mm)
PCI-E Power Connector	(6+2) Pin x1 [Total x2 Connectors] (550 mm)
SATA & Peripheral Assembly	SATA x3 + 4-Pin Peripheral x1 [Total x2 Cables] (450 mm + 150 mm + 150 mm + 150 mm)

Product Warranty: 1 Year

Warranty covers defects or dead-on-arrival items with original receipt and packaging. It excludes damage from misuse, power issues, unauthorized repairs, and software/data.
To claim, contact us within the warranty period with all accessories and packaging. Warranty is non-transferable and for the original buyer only.
For questions, contact us or check our warranty information.
